Electric spec

Ø High energy density and

efficiency

Ø Long life

Ø Good environmental

performance

Ø Free maintenance

Ø Safety and environmental

protection

Ø Easy to install

Nominal voltage

51.2V

Typical capacity

200Ah

Energy

10.24KWH

Max. charge voltage

58.4 V

Discharge cut-off voltage

40V-40.3V

Standard charge current

0.2C

Max charge current

0.5C

Standard discharge current

0.5C

Max discharge current

0.5C

Cycle life

3500times

Weight&Dimension

Weight (Approx.)

≈85Kg

Max. dimension（L×W×H）

620*693*180mm

Environment

Charge temperature

0℃～45℃

Discharge temperature

-20℃～55℃

Inverter+Mppt

3kw inverter+mppt

Optional

5kw inverter+mppt

Optional

Protection

Over-charge protection

YES

Over-discharge protection

YES

Over-current protection

YES

Over-temperature protect

YES

Short-circuit protection

YES

Thermal Switch

75±5℃

Resistance

≤20mΩ
